The shell is made of high temperature, high strength and UV resistant materials;
A wide temperature LCD is used, and the working temperature is - 20 ℃ ~ 60 ℃;
Wider voltage input range, 9 ~ 36VDC;
Excellent internal structure design and silica gel pad application make the screen excellent in shock absorption and shock resistance;
Equipped with military encoder switch, longer life and more stable performance;
Rich communication interface, can interface, supporting CANopen / can J1939, RS232 / RS485;
IP65 protection level of the whole machine.
5.7" TFT
640×480 px
65536 color
LED
700cd/m?
50000 hours
RISC Cortrx-A8 800MHz
256MB FLASH + 256MB DDR3
Real time clock + 32KB
1 USB Host
Serial port/USB
No
1 USB 2.0 high speed download/serial port
COM0: RS485; com2: RS232, one can interface (built-in isolation)
No
DC9V~DC36V
10W
DC24V (isolated)
<3ms
Over 50MΩ@500V DC
500V AC 1 minute
Navy Blue
Engineering plastics
180.3×133.9×70.7(mm)
171×125(mm)
1kg
-20~60℃
10~90%RH (non-condensing)
-30~80℃
10~90%RH (non-condensing)
10~500Hz, 30m/s?, X,Y,Z direction/hour
Natural air cooling
The front panel meets the requirements of IP65
Consistent with FCC Class A
Kinco dtools v3.3 and above
? Kinco Electric (Shenzhen) Ltd.
