Lightweight design, Slimmer body, faster and smoother movement speed.
Multi-slot pole.small cogging torque.
Feedback optional (High-resolution absolute encoder and Hall ).
Various frame sizes, covering loads of 3～25Kg.
The large split ratio and large hollow design.
The process update reduces the weight of the motor and increases the power density.
The temperature rise performance is excellent.The noise and vibration performance is excellent.
Multiple stator outer diameters to choose from, rated torque (customizable)
Stator： 25mm、38mm、43MM、50mm、57mm、60mm、68mm、70mm、77mm、85mm、94mm、104mm、123mm、127mm、140mm、160mm
Outer diameters：57mm、60mm、68mm、70mm、77mm、85mm、91mm、104mm、123mm、127mm、140mm、160mm
Torque range： 0.011～9.2Nm
| Model | Rated power Pn(W) | Rated speed Nn(rpm) | Mechanical time constantτm(ms) | Torque constant Kt(Nm/A) | Rated torque Tn(N.m) |
| FMC frameless torque motor | |||||
| FMC05705-0007-3028N-8DS00 | 75 | 3000 | 2.75 | 0.12 | 0.24 |
| FMC05707-0011-3528N-8DS00 | 117 | 3500 | 1.93 | 0.107 | 0.32 |
| FMC05714-0020-3027N-8DS00 | 200 | 3000 | 1.47 | 0.132 | 0.64 |
| FMC06012-0014-3128N-8DK00 | 146 | 3100 | 1.06 | 0.124 | 0.45 |
| FMC06805-0010-3034N-8DS00 | 101 | 3000 | 0.99 | 0.127 | 0.32 |
| FMC06808-0015-3034N-8DS00 | 157 | 3000 | 0.77 | 0.127 | 0.5 |
| FMC06813-0025-3034N-8DS00 | 251 | 3000 | 0.52 | 0.129 | 0.8 |
| FMC07605-0012-3038N-8DS00 | 126 | 3000 | 1.7 | 0.126 | 0.4 |
| FMC07712-0031-3033N-8DS00 | 314 | 3000 | 1.45 | 0.1 | 1 |
| FMC07730-0075-3035N-8DS00 | 750 | 3000 | 1.21 | 0.131 | 2.39 |
| FMC08505-0015-3042N-8DS00 | 157 | 3000 | 1.51 | 0.126 | 0.5 |
| FMC08508-0031-3042N-8DS00 | 314 | 3000 | 1.25 | 0.123 | 1 |
| FMC08513-0047-3042N-8DS00 | 471 | 3000 | 0.81 | 0.125 | 1.5 |
| FMC08518-0062-3042N-8DS00 | 628 | 3000 | 0.76 | 0.105 | 2 |
| FMC09114-0063-3046N-8DS01 | 630 | 3000 | 1.39 | 0.130 | 2 |
| FMC10414-0072-3055N-8DS01 | 723 | 3000 | 1.01 | 0.134 | 2.3 |
| FMC10422-0100-3047N-8DS00 | 1000 | 3000 | 1.44 | 0.13 | 3.18 |
| FMC10429-0100-2543N-8DS00 | 1050 | 2500 | 1.09 | 0.196 | 4 |
| FMC12330-0100-2060N-5DK00 | 1000 | 2000 | 0.045 | 0.22 | 4.78 |
| FMC12718-0090-2465N-8DS00 | 904 | 2400 | 1.46 | 0.161 | 3.6 |
| FMC12730-0160-2457N-8DS00 | 1600 | 2400 | 1.14 | 0.2 | 6.37 |
| FMC13224-0118-3243N-8DK00 | 1180 | 3220 | 0.801 | 0.132 | 3.5 |
| FMK frameless torque motor | |||||
| FMK02509-0004-5511-7DP02 | 36 | 5500 | 0.43 | 0.037 | 0.063 |
| FMK03807-0004-3518-7DP02 | 44 | 3500 | 0.46 | 0.051 | 0.12 |
| FMK04311-0008-3725N-7DP02 | 78 | 3700 | 0.52 | 0.1 | 0.2 |
| FMK05008-0016-5030H-10DP02 | 157 | 5000 | 0.61 | 0.089 | 0.3 |
| FMK06018-0020-2028N-10DP02 | 209 | 2000 | 0.51 | 0.172 | 1 |
| FMK06018-0026-3628N-10DP02 | 264 | 3600 | 1.91 | 0.103 | 0.7 |
| FMK07011-0025-3642N-10DP02 | 252 | 3650 | 0.48 | 0.116 | 0.66 |
| FMK08513-0037-2952N-10DP02 | 370 | 2950 | 1.1 | 0.14 | 1.2 |
| FMK08523-0073-3542N-10DP02 | 732 | 3500 | 1.02 | 0.134 | 2 |
| FMK11525-0117-3260N-10DP02 | 1173 | 3200 | 1.15 | 0.127 | 3.5 |
Frameless torque motor selection manual
