The preferred model for rail transit, high-speed subway.
Motherboard with three - prevention treatment, effective response to complex use environment.
Built-in isolated power supply, enhance reliability.
Dual USB Host design. Both front and back can be connected to USB devices.
4.3" TFT
95.04(W)¡Á53.86(H)
480¡Á272 px
16.77M true color
70/70/50/70(L/R/U/D)
500:1
LED
300cd/m?
More than 30000 hours
4-wire precision resistance network (surface hardness 4H)
ARM RISC 32Bit 800MHz
256MB Flash Memory+128MB Memory
Built-in RTC
2USB Host + 1SD Card
2¡ÁUSB Host/Serial port
10/100M adaptable Ethernet interface
USB Slave (Type B)/U Disk/Ethernet
COM0: RS232/RS485/RS422; COM2: RS232
None
DC12V~DC28V, inbuilt isolated power supply
3.5W@24VDC
<3ms
Over 50M¦¸@500V DC
500V AC 1 minute
Engineering plastics
154¡Á89¡Á60(mm)
146¡Á81(mm)
0.4Kg
-20~55¡æ
10~90%RH (non-condensing)
-20~60¡æ
10~90%RH (non-condensing)
10~500Hz, 30m/s?, X,Y,Z direction/hour
Natural air cooling
Conforming to IP65 certification (4208-93)
CE: EN61000-6-4:2007+A1:2011£¬EN61000-6-2:2005
Kinco DTools V4.1 and above version
The old version of the project can be opened directly by DTools software and downloaded to the new HMI.
Kinco HMI GH043U2&GH042EU2
